Foshan ABD Vertical Powder Coating Line

Place of Origin : Guangdong, China

Brand Name : ABD

Packaging Details : hot air convection powder curing oven package: load in container or according to customer's needs

Supply Ability : 30 Set/Sets per Month industrial commercial tunnel oven

Price : Negotiate

Payment Terms : L/C, T/T

Type : powder coating line

Substrate : Steel

Condition : New

Machine Type : powder coating curing oven, Plc Controller Programmable Logic Controller, Conveying Equipment, Drying Oven, Curing oven, Coating Equipment

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2022

Warranty of core components : 1 Year

Core Components : PLC, Motor

Coating : Powder Coating

Voltage : 220v 1phrase/380v 3phrase

Power : multi power

Dimension(L*W*H) : according to your needs

Warranty : 1 Year

Key Selling Points : Easy to Operate

Applicable Industries : Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Home Use, Retail, Construction works

Showroom Location : Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka,

Weight (KG) : 6000

After-sales Service Provided : Engineers available to service machinery overseas

Heating system : gas/electric/LPG/Diesel etc

Temperature : generally between 180-220℃, can be set according to customer needs

Wall panel : Rock wool steel board,150 mm thick,anti-flame and heat-insulation

Control system : process setting system:could set baking temperature etc

Oven type : one door, two doors(pass-type) and "bridge" type

Total powder : various according to different heating systems

Metal car rims Powder Coating Oven : iron car rims Powder Coating Oven

Iron profile Powder Curing Oven : aluminium Powder Heating Oven

Car powder curing furnace : metal doors powder heating machine

Contact Now

Hot Air Convection Powder Coating Oven

Product Description

Inside Size(mm)	10000x2500x3000mm (LXWXH)
Outside size(mm)	10300x2800x3300mm (LXWXH)
Wall panel	Rock wool steel board,150 mm thick,
Wall panel	anti-flame and heat-insulation
Door	Pass-type doors,2 sets
Fan	1 set 5.5 kw high-temperatute fan,air flow capacity:9000m³/h
Fan	Fan and burner box inner is 1.2 mm thick steel,out is also 150mm thick rock wool panel to keep heat
Heating system	1set of Riello RG5S natural gas burner,250000KCal/h,gas operation pressure:5KPa-8KPa,Gas consume for one hour:20-30m³/h
	max temp:250 ℃, heating time: 20-25 min (180-250℃)
	with heat exchanger,stainless steel chimney
Control system	Temperature alarm(With inductor in the oven) ,stop button,process setting system:could set baking time and temperature,when baking time arrive,stop automaticly,wire color:yellow/green for earth and 3 phases should be red,light blue and white
Total power	5.5kw

Powder coating oven with track rail:

Foshan ABD Vertical Powder Coating Line

Powder coating oven with hanging rail:

Foshan ABD Vertical Powder Coating Line

Powder coating oven components:

Foshan ABD Vertical Powder Coating Line

Company Information

Yantai Colin Coating Equipment Co., Ltd is a professional environmental quipment manufacture,the company products varied coating quipments like powder coating machine, powder coating booth, powder coating oven,powder reciprocator,powder coating production line,cyclone recovery systerm,hot air drying oven, drying boxes and drying tunnel,hanging conveyor,automatic spray pre-treatment etc.

Workshop

Foshan ABD Vertical Powder Coating Line

Our Services

First Pre-sale services:

1). Select equipment model;

2). Design and manufacture according to client’s special requirement.

3). Train technical personal for clients.

Second Services during the sale:

1). Pre-check and accept products ahead of delivery.

2). Help clients to draft solving plans.

Third After-sale service:

1). Assist clients to prepare for the first construction scheme.

2). Install and debug the equipment.

3). Train the first-line operators.

4). Examine the equipment.

5). Take initiative to eliminate the trouble rapidly.

6). Provide perfect service.

7). Provide technical exchanging

Fourth Overseas Installiation Service

If the customers need overseas installiation service, we can send professional engineer to install for customers in your workshops but need to charge the cost.

FAQ

Customization of powder coating Equipment

Before customized design for your painting line, there are some points needing your confirmation:
1). What's the size (L*W*H) of your workshop for this painting line?
2). What's the shape, size(L*W*H), weight of parts to be painted? Could you please send me some pictures of the parts?
3). How many parts to be painted in a working day (8hours)?
4). Is there any oil or rust on the surface of the parts? If yes, how about the amount?
5). How many times do you want to paint such parts?
6). What's your desired heating source for baking the paint, diesel, natural gas or electric?
7). How about the electric voltage and frequency in your palce?
